The Ultimate Guide to the Trident X-VIEW Series: Elevating Dental Diagnostics in Bangladesh
In the rapidly evolving world of modern dentistry, precise imaging is the cornerstone of successful treatment planning. Whether you are performing a complex dental implant surgery, plotting orthodontic alignments, or running routine maxillofacial screenings, the clarity of your diagnostic data directly impacts your clinical outcomes.
As a leading importer and supplier of world-class medical equipment in Bangladesh, Focus Imaging BD is proud to bring international innovation straight to your clinic. We are the official supplier of the Trident X-VIEW Series—an advanced, Italian-engineered extraoral digital dental imaging system designed to redefine diagnostic accuracy.
Why Choose the Trident X-VIEW Platform?
The Trident X-VIEW family is widely recognized for combining top-tier European craftsmanship with an intuitive, fluid workflow. Designed and manufactured in Italy by Trident S.r.l., this platform offers completely customizable modular configurations tailored to the scale of your dental practice.
The system is engineered across two primary core configurations:
- X-VIEW 2D PAN Series: Dedicated flat panoramic and cephalometric radiography. Ideal for general dentistry and high-volume orthodontic clinics, featuring modular upgrade paths (like the X-VIEW 2D PAN UP) so your equipment grows alongside your practice.
- X-VIEW 3D PAN (CBCT) Series: Bringing Cone Beam Computed Tomography (CBCT) into your diagnostic toolkit. It delivers high-resolution 3D volumetric views alongside standard digital panoramic imaging for specialized implantology and oral surgeries.
Premium Technical Specs Built for Precision
When investing in high-end clinic infrastructure, technical performance matters. The Trident X-VIEW excels with clinical specifications tailored to optimize both patient safety and image fidelity:
- Advanced Radiation Control: Utilizes a high-frequency, pulsed DC X-ray generator paired with a 0.5 mm focal spot. The pulsed technology dramatically lowers the diagnostic radiation dose, ensuring exceptional safety for your patients.
- Ultra-HD Resolution: Delivers exceptionally sharp 3D voxel resolution down to 65 μm, capturing fine anatomical microstructures and root canal networks.
- Rapid Acquisition Windows: Standard adult panoramic scans take under 15 seconds, while specialized single-shot cephalometric exposures capture high-contrast profiles in less than 500 ms to completely avoid motion artifacts.
- Perpetual Software Suite: Bundled with Trident’s proprietary Deep-View® diagnostic environment and Xelis implant planning software. Best of all, it features a lifetime license with zero annual subscription or renewal fees.
Comprehensive Technical Comparison Table
To help your procurement team select the exact configuration required for your facility, here is the full technical breakdown across the X-VIEW product configurations:
| Technical Parameter | 2D Panoramic Series (PAN / CEPH) | 3D CBCT Series (3D PAN / CEPH) |
|---|---|---|
| X-Ray Generator Type | High-Frequency Constant Potential Pulsed DC | High-Frequency Constant Potential Pulsed DC |
| Focal Spot Size | 0.5 mm (IEC 60336) | 0.5 mm (IEC 60336) |
| Tube Voltage | 61 kV to 85 kV | 61 kV to 85 kV |
| Anode Current | 5 mA to 10 mA | 5 mA to 10 mA |
| Primary Detector | High-sensitivity CMOS Flat Panel | Amorphous Silicon (a-Si) / IGZO Flat Panel |
| Field of View (FOV) | N/A (Standard 2D Flat Plane) | Multi-FOV selection up to 11 x 14 cm |
| Minimum Voxel Size | N/A | 65 μm (Ultra-HD resolution) |
| Pan Exposure Time | 14.3 to 15.0 seconds | 14.3 to 15.0 seconds |
| Ceph Exposure Time | < 500 ms (Single-Shot) | < 500 ms (Single-Shot) |
| Patient Positioning | 4-point rigid alignment with dual lasers | 4-point rigid alignment with dual lasers |
| User Interface | 7-inch integrated color touchscreen | 7-inch integrated color touchscreen |
| Software Suite | Deep-View® 2D Suite | Deep-View® 3D & Xelis Implant Planning |
| Software License Cost | Perpetual (Lifetime Free) | Perpetual (Lifetime Free) |
| Country of Origin | Italy (Trident S.r.l.) | Italy (Trident S.r.l.) |
Focus Imaging BD: Your Trusted Medical Technology Partner
At Focus Imaging BD, our corporate mission has always been simple: empower healthcare professionals across Bangladesh with premium, reliable, and cutting-edge equipment at the best possible price points.
Beyond dental radiology, we supply hospitals, diagnostic centers, and clinics nationwide with a diverse catalog of world-class medical equipment:
- Color Doppler Ultrasonography (USG) Systems (Proud Official Distributor of SonoScape)
- High-Frequency Digital X-Ray & C-Arm Systems
- ICU, NICU, & Operating Theater (OT) Equipments
- Advanced CT Scan & MRI Systems
- ECG, ETT, and EEG Diagnostics
When you source your machinery through us, you get more than a crate at your doorstep. We back every deployment with official manufacturer warranties, seamless spare parts availability, and a dedicated team of biomedical service engineers ready to handle installation, calibration, and routine maintenance.
Get a Custom Quotation Today
Ready to upgrade your dental facility with Trident X-VIEW’s Italian precision? Let our diagnostic experts help you choose the exact configuration for your clinical needs.
Get in touch with our team or visit our corporate office in Dhaka to request a formal quotation:
- 📍 Corporate Office: Focus Imaging BD, Tropicana Tower (Lift-8, B/1), 218, Shaheed Syed Nazrul Islam Sarani (Topkhana Road), Purana Paltan More, Dhaka-1000, Bangladesh.
- 📞 Call Us Directly: +8801739765968 / +8801917746166
- 📧 Email: mail@focusimagingbd.com
- 🌐 Official Website: focusimagingbd.com
