Transforming Healthcare: Upgrade to Digital Radiography with the Angell Technology TCQ-III Wireless Flat Panel Detector
In the fast-evolving landscape of modern medicine, imaging speed and diagnostic precision dictate the efficiency of patient care. For many clinics and hospitals across Bangladesh, conventional analog X-ray systems are still highly reliable, but they bottleneck your workflow due to slow chemical film development.
As the official direct importer of premium medical imaging technology in Bangladesh, Focus Imaging BD has the ultimate solution to modernize your department without the immense cost of buying a completely new X-ray machine. We bring you the Angell Technology TCQ-III (TCQ 3) Wireless Flat Panel Detector, a game-changing digital radiography (DR) upgrade designed to retrofit seamlessly into your existing equipment. Because we import these units directly from the manufacturer, we guarantee authentic products, full warranty backing, and the most competitive pricing in the market.
Product Overview & Technical Specifications
To give you complete clarity on how this advanced system functions, we have broken down all the essential product features, technologies, and specifications in the table below:
| Feature Category | Technical Specifications & Clinical Benefits |
|---|---|
| Model Name | Angell Technology TCQ-III (TCQ 3) Wireless Flat Panel Detector |
| Active Imaging Area | 17 × 17 inches (43 × 43 cm) – Provides full-field coverage suitable for all anatomical structures. |
| Sensor Technology | Amorphous Silicon (a-Si) thin-film transistor (TFT) matrix. |
| Scintillator Material | Premium Cesium Iodide (CsI) – Delivers high-resolution imaging with lower patient radiation doses compared to traditional film. |
| Pixel Configuration | 3072 × 3072 pixel matrix with a fine 139 μm pixel pitch for exceptional spatial resolution. |
| Contrast Resolution | 16-bit A/D conversion – Offers a massive grayscale range to reveal subtle tissue and bone structures. |
| Trigger Technology | Intelligent Automatic Exposure Detection (AED) – Senses X-rays automatically without needing a physical sync cable to your X-ray generator. |
| Wireless Connectivity | High-speed dual-band 2.4GHz / 5.8GHz (IEEE 802.11 a/b/g/n/ac) transmitting up to 1167 Mbps. |
| Workflow Speed | Raw preview images are delivered to the technician’s monitor in ≤ 7 seconds for fast patient turnaround. |
| Onboard Processing | Real-time hardware correction technology for automatic flat-field calibration and pixel defect masking. |
| System Compatibility | Fully DICOM 3.0 compliant – Connects directly to local PACS, electronic medical records (EMR), and cloud networks. |
Why Choose Focus Imaging BD as Your Diagnostic Partner?
When you acquire your Angell TCQ-III detector from Focus Imaging BD, you are partnering directly with the importer. This unlocks unique advantages for your medical facility:
- Direct Import Pricing: Eliminate third-party middlemen margins to secure the best possible price in Bangladesh.
- Genuine Spare Parts & Support: As the importer, we maintain direct access to original manufacturer parts, calibration tools, and firmware updates.
- Expert Local Engineering: Our dedicated technical team handles complete on-site installation, configuration with your current X-ray machine, and comprehensive staff training.
